Title:Modeling Disrupted Transportation Infrastructure System Due to Fallen Trees under Wind Hazards
Authors:Guangyang Hou and Suren Chen
University:Colorado State University
Publication Date:Sep 2023
Report #:MPC-23-505
Project #:MPC-617
TRID #:01898473
Keywords:finite element method, risk assessment, service disruption, street closure, transmission lines, trees, urban areas, wind
Type:Research Report – MPC Publications

Abstract

Tree failures due to strong winds in urban areas cause extensive direct and indirect economic and environmental loss, including disrupting adjacent infrastructures, such as buildings, underground pipelines, roads, and overhead powerlines. To effectively improve the resilience of a community subjected to extreme wind events through prevention, response, and recovery, it becomes critical to rationally assess the risks of wind-induced tree failures and the disruptions to different types of infrastructures due to fallen trees. An integrated probabilistic methodology to model the performance of disrupted infrastructures is developed for fallen urban trees subjected to extreme winds in a typical community. First, the finite-element modeling of the trees subjected to wind loads is conducted and, based on which, the windthrow fragility curves of several typical urban tree species are developed. Second, a probabilistic framework is developed based on the fragility results to characterize the disrupted scenarios and further predict the disruption probability of some critical infrastructures due to fallen trees. The matrix-based system reliability (MSR) method is introduced to assess the transportation network performance. The proposed framework and MSR method are demonstrated in detail while studying the overhead powerline and transportation network of a small urban community in the city of Fort Collins, Colorado. In the demonstrative example, the probabilities of powerline disruption, road closure, and origin-destination (OD) disconnection and travel time reliability under different wind conditions are predicted. Finally, mitigation efforts such as crown thinning of trees are discussed to reduce possible risks of disrupting the infrastructures.

How to Cite

Hou, Guangyang, and Suren Chen. Modeling Disrupted Transportation Infrastructure System Due to Fallen Trees under Wind Hazards, MPC-23-505. North Dakota State University - Upper Great Plains Transportation Institute, Fargo: Mountain-Plains Consortium, 2023.
